Built by D. Perry Sinnett of Orr’s Island in 1904 for Capt. Everett Gatchell. Original in MMM collection: 67.2331.

Two sheets: Lines and offsets, outboard profile (above waterline), and longitudinal construction drawings by Arno Day.

Scale: 1”=1’.

Does not include midship section, plan view, scantlings, or other specifications.

Link for digital download of plans will be available after purchase and sent to your email.
